Blog Optimization - 3. Image Optimization

Table of Contents

Blog Creation Series

TitleLink
1. Basic Settingshttps://witch.work/posts/blog-remake-1
2. HTML Design of the Main Pagehttps://witch.work/posts/blog-remake-2
3. Structure Design of Post Detail Pageshttps://witch.work/posts/blog-remake-3
4. Enabling Relative Paths for Imageshttps://witch.work/posts/blog-remake-4
5. Minor Page Configuration Improvements and Deploymenthttps://witch.work/posts/blog-remake-5
6. Layout Design of Page Elementshttps://witch.work/posts/blog-remake-6
7. Design of Main Page Componentshttps://witch.work/posts/blog-remake-7
8. Design of Article List/Content Page Componentshttps://witch.work/posts/blog-remake-8
9. Automatic Generation of Article Thumbnailshttps://witch.work/posts/blog-remake-9
10. Design Improvements for Fonts, Cards, etc.https://witch.work/posts/blog-remake-10
11. Adding View Counts to Postshttps://witch.work/posts/blog-remake-11
12. Page Theme and Post Search Functionalityhttps://witch.work/posts/blog-remake-12
13. Improvements to Theme Icons and Thumbnail Layouthttps://witch.work/posts/blog-remake-13
14. Changing Post Classification to Tag-Basedhttps://witch.work/posts/blog-remake-14
Optimization of Main Page Calculationshttps://witch.work/posts/blog-opt-1
Creating Pagination for Article Listhttps://witch.work/posts/blog-opt-2
Uploading Images to CDN and Creating Placeholdershttps://witch.work/posts/blog-opt-3
Implementing Infinite Scroll on Search Pageshttps://witch.work/posts/blog-opt-4

1. Image Optimization

This article focuses on overall image optimization. First, let's take a look at Lighthouse's suggestions and diagnostics for the article list page. The score is disappointing, but even the longest journey begins with a single step, so let's do what we can.

category-page-diagnostics

It suggests providing appropriate sizes for images. Let's specify sizes for the Image tag in the Card component.

function Card(props: Props) {
  /* omitted */
  <Image
    className={styles.image}
    src={image}
    alt={`${image} photo`}
    width={200}
    height={200}
    sizes='100px'
  />
  /* omitted */
}

Set the image's minimumCacheTTL to 30 days, which can be configured in next.config.js.

const nextConfig = {
  images: {
    unoptimized: false,
    imageSizes: [64, 384],
    deviceSizes: [768, 1920],
    domains: ['res.cloudinary.com'],
    minimumCacheTTL: 60 * 60 * 24 * 30,
  },
  reactStrictMode: false,
  swcMinify: true,
};

By opening the browser's developer tools, accessing the Network tab, and inspecting the response headers of the images from the blog page, you will find a Cache-Control: public, max-age=0, must-revalidate entry.

Setting the minimumCacheTTL will change the max-age in the Cache-Control header to the specified value. In my case, it was adjusted to 2592000.

While it's recommended to keep this low to avoid intentionally deleting caches, I believe that for images used on a blog, refreshing the cache once every 24 hours is sufficient. If an image update is necessary, a daily refresh should be adequate.

2. Trying Cloudinary

I found a very helpful article titled Building a Fast Animated Image Gallery with Next.js published by Vercel!

This blog states that Cloudinary was used to serve images. Let's give this a try.

First, sign up for Cloudinary. I signed up using Google, and you'll see the following screen on your dashboard.

after-login

From the left menu, enter the Media Library to upload assets. Its UI is quite similar to Google Drive, allowing for drag-and-drop uploads of images.

For example, after uploading my profile picture to the samples folder, I could obtain a URL like this. Hovering over the image shows a button to copy the URL. The structure of the URL is referenced in the official documentation.

https://res.cloudinary.com/<cloud_name>/<asset_type>/<delivery_type>/<transformations>/<version>/<public_id_full_path>.<extension>

https://res.cloudinary.com/my_cloud_name/asset_type(image)/delivery_type/version/folder_name/witch_xjp39k.jpg

To call this via the API, we first need to set the API keys in .env.local. You can retrieve those keys from the Access Keys menu under Settings.

NEXT_PUBLIC_CLOUDINARY_CLOUD_NAME=replace
CLOUDINARY_API_KEY=replace
CLOUDINARY_API_SECRET=replace

Add the following settings in next.config.js to allow fetching images from res.cloudinary.com.

/* Edit only nextConfig */
const nextConfig = {
  images: {
    unoptimized: false,
    imageSizes: [64, 384],
    deviceSizes: [768, 1920],
    /* Add cloudinary to domains */
    domains: ['res.cloudinary.com'],
  },
  reactStrictMode: false,
  swcMinify: true,
};

Now we can fetch images using the URL as follows.

<Image
  src={`https://res.cloudinary.com/${process.env.NEXT_PUBLIC_CLOUDINARY_CLOUD_NAME}/image/upload/v1686541466/samples/witch_xjp39k.jpg`}
  alt='Profile Picture'
  width={300}
  height={300}
/>

To use this on Vercel, add the above environment variables there as well. The current environment variables look as follows.

vercel environment variables

3. Designing the Image Serving System

Previously, all images were included during the build of the website. Now we will be using Cloudinary. But should we completely abandon the existing image storage method?

While it is a possibility, I believe it is not advisable to restrict ourselves to only new methods when changing the storage approach. Since Cloudinary is not unlimited, we might have to revert to the existing storage method in the future. Furthermore, we may end up using another cloud storage solution.

The reason for such concerns is, of course, cost. I can only use a free or very cheap plan, while Cloudinary's paid plans are quite expensive...

I have no money

Thus, let's allow the user to choose where to store images in blog-config.ts under blogConfig. The default value will be local.

If the value of blogConfig.imageStorage is local, store it in public/images, and if it is cloudinary, store it in Cloudinary, while saving two URLs based on the user's setting in blogConfig.imageStorage.

interface BlogConfigType {
  name: string;
  title: string;
  description: string;
  picture: string;
  url: string;
  social: {
    Github: string;
    BOJ: string;
  };
  comment: {
      type: 'giscus';
      repo: string;
      repoId: string;
      category: string;
      categoryId: string;
      lang?: 'ko' | 'en'; // defaults to 'en'
      lazy?: boolean;
    };
    /* Enable selection of image storage */
  imageStorage: 'local' | 'cloudinary'; // defaults to 'local'
  thumbnail: string;
  googleAnalyticsId?: string; // gtag id
}

4. Main Page Image Optimization

Excluding my profile photo, there are only four images on the main page, which are project images. As these are not dynamically generated, changing them is straightforward. After uploading to Cloudinary, simply change the src of the corresponding image tags.

First, in blog-project.ts, modify the project image URL type to accommodate both local and Cloudinary URLs.

// blog-project.ts
export interface projectType {
  title: string;
  description: string;
  image: {
    local: string;
    cloudinary: string;
  };
  url: {
    title: string;
    link: string;
  }[];
  techStack: string[];
}

Next, create a /blog folder in the Cloudinary media library.

Create Blog Folder

Upload the project images (those that were in /public/project) into this newly created folder. Once the URLs are generated, assign them to the project images in projectList.

I was concerned that exposing the entire URL would reveal the Cloudinary cloud name, but according to Cloudinary's official site, it’s fine for the cloud name and API key to be exposed.

As long as the API secret remains hidden, we can proceed. Therefore, let's store the Cloudinary URL in blog-project.ts as follows.

const projectList: projectType[] = [
  {
    title: 'Witch-Work',
    description: 'My personally created blog',
    image: {
      local: '/witch.jpeg',
      cloudinary: 'https://res.cloudinary.com/desigzbvj/image/upload/v1686565864/blog/witch_t17vcr.jpg'
    },
    /* URL and techStack properties omitted */
  },
  /* Other project objects omitted */
];

In the ProjectCard component displaying the projects, use different image URLs based on blogConfig.imageStorage.

// src/components/projectCard/index.tsx
function ProjectCard({project}: {project: projectType}) {
  return (
    <Link className={styles.wrapper} href={project.url[0].link} target='_blank'>
      <article className={styles.container} >
        <div className={styles.titlebox}>
          <ProjectTitle title={project.title} />
        </div>
        <div className={styles.imagebox}>
          <ProjectImage title={project.title} image={project.image[blogConfig.imageStorage]} />
        </div>
        <div className={styles.introbox}>
          <ProjectIntro project={project} />
        </div>
      </article>
    </Link>
  );
}

5. Post Thumbnail Image Optimization

Currently, the thumbnails are generated in src/plugins/make-thumbnail.mjs, where the file path is stored in data._raw.thumbnail. Therefore, let's change the existing file path to thumbnail.local and add thumbnail.cloudinary.

To do this, we need to upload the images first while generating thumbnails. The current code for thumbnail generation works well, so let's just add the code to upload to Cloudinary in the makeThumbnail function.

Upload the image stored in thumbnail.local to Cloudinary and save the URL in thumbnail.cloudinary. According to the upload API documentation response, the image URL is contained in the secure_url of the response. We'll designate this as the thumbnail URL. We will not use the http version as it will trigger a security warning.

export default function makeThumbnail() {
  return async function(tree, file) {
    const images = extractImgSrc(tree);
    if (images.length > 0) {
      file.data.rawDocumentData.thumbnail = {
        local: images[0],
      };
    } else {
      const title = file.value.split('\n')[1].replace('title: ', '');
      const { headingTree, sourceFilePath } = file.data.rawDocumentData;
      const b = await createThumbnailFromText(title, headingTree, sourceFilePath);
      file.data.rawDocumentData.thumbnail = {
        local: b,
      };
    }
    /* At this point, there is at least one thumbnail */
    const results = await cloudinary.v2.uploader.upload(
      join(__dirname, 'public', file.data.rawDocumentData.thumbnail.local), {
        folder: 'blog/thumbnails',
        use_filename: true,
      }
    );
    file.data.rawDocumentData.thumbnail.cloudinary = results.secure_url;
  };
}

Now, modify the Card component to use the thumbnail based on the specified imageStorage in blog-config.ts. Update the CardProps and similar types throughout the code.

// src/components/card/index.tsx
export interface CardProps {
  title: string;
  description: string;
  thumbnail?: {
    local: string;
    cloudinary: string;
  }
  date: string;
  tags: string[];
  url: string;
}

function Card(props: CardProps) {
  const { title, description, thumbnail, date, tags, url } = props;
  return (
    <Link className={styles.link} href={url}>
      <article className={styles.container}>
        {thumbnail ?
          <div>
            <Image
              className={styles.image}
              src={thumbnail[blogConfig.imageStorage]}
              alt={`${title} photo`}
              width={200}
              height={200}
              sizes='100px'
            />
          </div>
          :
          null
        }
        <Intro title={title} description={description} date={date} tags={tags} />
      </article>
    </Link>
  );
}

The above section of code, which had to be modified for thumbnail fetching based on blogConfig.imageStorage, can be reviewed in the previous commit history.

6. Removing Duplicates and Optimizing Images

However, there is an issue. Each time I run dev or build, makeThumbnail continuously executes and uploads images repeatedly.

To resolve this, provide a public ID at upload and set overwrite to false (to prevent overwriting when the same ID exists).

Modify the upload API call in makeThumbnail as follows.

export default function makeThumbnail() {
  return async function(tree, file) {
    const images = extractImgSrc(tree);
    if (images.length > 0) {
      file.data.rawDocumentData.thumbnail = {
        local: images[0],
      };
    } else {
      const title = file.value.split('\n')[1].replace('title: ', '');
      const { headingTree, sourceFilePath } = file.data.rawDocumentData;
      const b = await createThumbnailFromText(title, headingTree, sourceFilePath);
      file.data.rawDocumentData.thumbnail = {
        local: b,
      };
    }
    /* At this point, there is at least one thumbnail */
    const results = await cloudinary.v2.uploader.upload(
      join(__dirname, 'public', file.data.rawDocumentData.thumbnail.local), {
        public_id: file.data.rawDocumentData.thumbnail.local.replace('/', '').replaceAll('/', '-').replaceAll('.', '-'),
        folder: 'blog/thumbnails',
        overwrite: false,
      }
    );
    file.data.rawDocumentData.thumbnail.cloudinary =
      `https://res.cloudinary.com/${process.env.NEXT_PUBLIC_CLOUDINARY_CLOUD_NAME}/image/upload/c_scale,w_300,f_auto/${results.public_id}`;
  };
}

Here, you can see that the image is being resized to 300px and the file format is optimized automatically by including c_scale,w_300,f_auto in the URL.

Perform the same optimization on project images by modifying the array in blog-project.ts like this.

// blog-project.ts
const projectList: projectType[] = [
  {
    title: 'Witch-Work',
    description: 'My personally created blog',
    image: {
      local: '/witch.jpeg',
      /* Notice that c_scale,w_400,f_auto is included in between. This format is referenced in the official transformation API documentation. */
      cloudinary: 'https://res.cloudinary.com/desigzbvj/image/upload/c_scale,w_400,f_auto/v1686565864/blog/witch_t17vcr.jpg'
    },
    url: [
      {
        title: 'URL',
        link: 'https://witch.work/'
      },
      {
        title: 'Github',
        link: 'https://github.com/witch-factory/witch-next-blog'
      },
    ],
    techStack: ['Next.js', 'React', 'TypeScript']
  },
]

7. Providing Blurred Images

No matter how fast the server sending the image is, nothing beats using a smaller image size. So let's prepare a placeholder to use while loading images.

Create a function that generates a blur image from the Cloudinary URL, which we will add in src/utils/generateBlurPlaceholder.ts.

Before doing this, install a library called imagemin. This library optimizes images, along with imagemin-jpegtran. Additionally, install the necessary types for these libraries.

npm install imagemin imagemin-jpegtran
npm install --save @types/imagemin
npm install --save @types/imagemin-jpegtran

This function will fetch a 16px jpg version of the Cloudinary URL image, optimize it using the imagemin library, and return it as a base64 encoded string.

// src/utils/generateBlurPlaceholder.ts
import imagemin from 'imagemin';
import imageminJpegtran from 'imagemin-jpegtran';

export default async function getBase64ImageUrl(imageUrl: string) {
  const response = await fetch(imageUrl.replace('w_300,f_auto', 'w_16,f_jpg'));
  const buffer = await response.arrayBuffer();
  const minified = await imagemin.buffer(Buffer.from(buffer), {
    plugins: [imageminJpegtran()],
  });
  return blurURL;
}

Then, in the makeThumbnail function, use the above function to generate the blurred URL for the thumbnail.

// src/plugins/make-thumbnail.mjs
export default function makeThumbnail() {
  return async function(tree, file) {

    /* Thumbnail generation and Cloudinary upload parts omitted */

    file.data.rawDocumentData.thumbnail.cloudinary =
      `https://res.cloudinary.com/${process.env.NEXT_PUBLIC_CLOUDINARY_CLOUD_NAME}/image/upload/c_scale,w_300,f_auto/${results.public_id}`;

    /* The following part for generating the blurURL has been added */
    file.data.rawDocumentData.thumbnail.blurURL = await getBase64ImageUrl(file.data.rawDocumentData.thumbnail.cloudinary);
  };
}

Make sure the Card component uses this blur placeholder as well.

export interface CardProps {
  title: string;
  description: string;
  thumbnail?: {
    local: string;
    cloudinary: string;
    blurURL?: string;
  }
  date: string;
  tags: string[];
  url: string;
}

function Card(props: CardProps) {
  const { title, description, thumbnail, date, tags, url } = props;
  return (
    <Link className={styles.link} href={url}>
      <article className={styles.container}>
        {thumbnail ?
          <div>
            <Image
              className={styles.image}
              style={{ transform: 'translate3d(0, 0, 0)' }}
              src={thumbnail[blogConfig.imageStorage]}
              alt={`${title} photo`}
              width={200}
              height={200}
              sizes='200px'
              placeholder={'blurURL' in thumbnail ? 'blur' : 'empty'}
              blurDataURL={thumbnail.blurURL}
            />
          </div>
          :
          null
        }
        <Intro title={title} description={description} date={date} tags={tags} />
      </article>
    </Link>
  );
}

As a result, you will observe that a blurred image briefly appears while the image loads.

Additionally, the Image component has a style={{ transform: 'translate3d(0, 0, 0)' }} property added. This performs a CSS transform of vector (0,0,0), essentially resulting in no positional change.

The reason for using this seemingly pointless CSS is to ensure that some devices use GPU rendering for this element. This is particularly effective in Safari.

While this may not have been a critical need for my blog, other tricks are introduced in the Next.js Image Gallery Building Guide.

References
